Among leading pre painted aluminum coil suppliers in China, we supply products of the following specification.
Product Name |
pre painted aluminum coil |
Alloys available |
1100, 1050, 1060, 3003, 3004, 3005, 3104, 3105, 5005, 5052, 5754 |
Thickness |
0.25mm to 2.0mm |
Width |
Standard width: 1000mm,1220mm 1250MM 1500mm |
Special width : 984mm, 1200mm, 1240mm, 1270mm, 1520mm, 1620mm |
|
Diameter |
Standard dia: 500mm |
Interior dia: 150mm, 300 mm, 405mm, 505mm, 510mm |
|
Outer diameter: 1200mm |
|
Weight |
2.5 T/coil, 3.0 T/coil |
Coating thickness |
PE:>=16 micron , PVDF:>=25 micron |
Coating paint |
PVDF, PE(Polyester), epoxy, polyamide, polyurethane |
Color |
Soid. metallic, high gloss.stone.timber.brush.mirror.sparkling, RAL or as required |
Impact Resistance |
No peeling or cracking(50 kg/cm) |
Application of pre painted aluminium coil:
It is widely used for ACP, roofing, ceiling,curtain wall, window, gutter,aluminum tile,door ,can ,box or other building decoration.
Advantage of pre painted aluminum coil:
1. very good weather resistance: can used more than 20 years without color fading
2. high impact resistance: not easy to damage the painting when bending
3. Smooth and spotless surface. High technology and high-performance roller coating art can control the precision and smoothness of surface effectively to endow constructions with even color. They make constructions bright and neat. They are blended into one integral whole.
4. Super processing ability. we controls material purchase and technical process of production strictly, so the plates made by us are characterized by both excellent stiffness but also excellent processing ability. They could be bonded, cut, split, slotted, blended, pressed, drilled, connected and fastened. Edge compression molding can be done. All of their performances can take the place of imported similar products.
